Electrical Group



KDT Services Electrical New Single ImageKDT Electrical Group provides support and assistance in the preparation of drawings, engineering designs and services to the Electrical and Control System for Plants and Machinery of KHI Plant & Infrastructure Company.



KDT Electrical Group strives to uphold high standards of performance in our services. We are committed to build a solid reputation of confidence with sincerity and character in our work. Our group will be known and valued for its responsive, reliable and systematic approach to project priorities, scope and schedule.



The Electrical Group is composed of 3 sub-groups:

    • Electrical 1:Specializing in Electrical designs and drawings

      Main Works:

      1. Planning and designing of Power Distribution System
      2. Planning and designing of Wiring Diagram
      3. Planning and designing of Equipment Arrangement of Power Stations (Electrical, Control rooms)
      4. Planning and designing of Cable Route
      5. Planning and designing of Grounding, and Lightning Systems
      6. Preparation of construction documents such as Cable Schedule, Connection Diagram, Typical and Material drawings, etc.
    • Electrical 2:Specializing in Electrical designs applications

      Main Works:

      1. Application of ETAP software
      2. Application of EDPP software
      3. Application of Lighting Illuminance software
      4. Planning and design of Electrical Cable Rack System such as Cable Rack Route, Cable Rack Support, and Cable Rack Support Fabrication drawings.
      5. Planning and designing of Equipment Location for Power, Lighting and Receptacle System, Auxiliary System such as ITV, CCTV, Paging, etc.
      6. Preparation of Bill of Quantities and/or Material Take-Off for Electrical works
    • Control Section:
      Specializing in Control & Instrument (C&I) designs and drawingsMain Works:

      1. Planning and designing of Wiring Diagram
      2. Planning and designing of Hook-up drawings of field instruments
      3. Planning and designing of Equipment Location of field instruments and sensors
      4. Planning and designing of plant control system such as DCS, PLC, etc.
      5. Planning and design of C&I Cable Rack System such as Cable Rack Route, Cable Rack Support, and Cable Rack Support Fabrication drawings.
      6. Preparation of Bill of Quantities and/or Material Take-Off for C&I works

Scope of Work:

  • Preparation of reference and construction drawings.
  • Design Works for electrical and control & instrument
  • 3D Modeling of electrical and control & instrument
  • Bill of Quantities, Material Take-off
  • Support to KHI engineers for Factory Acceptance Test (FAT), Commissioning
  • Project site inspection, supervision and progress monitoring



Tools:

  • AutoCAD
  • Plant Design and Management System (PDMS)
  • Electrical – Data Processing Program (EDPP)
  • Electrical Transient and Analysis Program (ETAP)
  • Navisworks
  • Microsoft Office (Word, Excel, Access)
  • Lightning Illuminance Software



Future Plan Capabilities:

  • Plant Design and Management System (PDMS) Electrical

Sample Projects:

  • Cement Plants (Indonesia, Saudi Arabia, Turkmenistan, Vietnam, Morocco)
  • Ferronickel processing Plants (Indonesia, South Korea)
  • Flue Gas Desulfurization Plants (Saudi Arabia, Vietnam, Yangzhou)
  • Chemical Plants (Turkmenistan)
  • Power Plants (Guizhou, Mindanao)



We strive to uphold high standards of performance in our services.  We are committed to build a solid reputation of confidence with sincerity and character in our work.  Our group will be known and valued for its responsive, reliable and innovative approach to project priorities, scope and schedule.
